Inconel 600 Sheets & Plates Supplier (Alloy 600, UNS N06600)

Inconel 600 Sheet, Plate and Strip to ASTM B168

Inconel 600 sheet and plate is nickel-chromium-iron alloy (UNS N06600, W.Nr. 2.4816) flat product to ASTM B168 / ASME SB168, used for high-temperature and corrosive service: plate from 5 mm thick, sheet and strip below 5 mm, supplied hot-rolled or cold-rolled and annealed.

Dinesh Tube India supplies Inconel 600 sheets, plates, strip and coil from Mumbai, in full sizes or cut to size, with EN 10204 3.1 mill test certificates.


Table of Contents


What Is Inconel 600 Sheet and Plate?

Alloy 600 is a nickel-chromium-iron alloy with at least 72% nickel and 14–17% chromium. The high nickel content resists chloride stress corrosion cracking and many reducing environments, while the chromium gives oxidation resistance at high temperature. It is a solid-solution alloy, so it is used in the annealed or as-rolled condition and is not age hardened.

Inconel 600 sheets and plates

Sheet, Plate, Strip or Tubesheet: Which Do You Need?

Product formASTM B168 definitionTypical supply
Plate5.00 mm (3/16") and thicker, over 250 mm wideHot-rolled, annealed or as-rolled
SheetUnder 5.00 mm thick, 600 mm and widerCold-rolled and annealed
Strip / coilCold-rolled, under 5.00 mm thick, under 600 mm wideCold-rolled and annealed; slit coil on request
Tubesheet blankCut from plate to the required diameter and thicknessCircles or blanks; drilling by the fabricator

For Inconel 600 tubes and pipes, see our Inconel tubes and Inconel pipes.

Which Standard and Condition Should You Specify?

  •   ASTM B168 / ASME SB168: plate, sheet and strip in UNS N06600; general requirements in ASTM B906 / ASME SB906.
  •   Other specifications sometimes named on orders: SAE AMS 5540, DIN 17750 and EN 10095 (W.Nr. 2.4816).
  •   Condition: hot-rolled annealed, hot-rolled as-rolled, or cold-rolled annealed. The condition sets the mechanical property minimums, so state it in the order.

Inconel 600 Mechanical Properties by Condition

Condition (ASTM B168)Tensile strength, minYield strength (0.2%), minElongation, min
Hot-rolled plate, annealed550 MPa (80 ksi)240 MPa (35 ksi)30%
Hot-rolled plate, as-rolled586 MPa (85 ksi)240 MPa (35 ksi)30%
Cold-rolled sheet and strip, annealed550 MPa (80 ksi)240 MPa (35 ksi)30%

B168 sets these minimums by product condition rather than by thickness. Typical annealed values are higher (about 655 MPa tensile, 310 MPa yield and 40% elongation) and are not guaranteed minimums. Density 8.47 g/cm³; melting point about 1413 °C.

Inconel 600 Chemical Composition (%)

CMnSiSCrNiCuFe
0.15 max1.00 max0.50 max0.015 max14.00 – 17.0072.00 min0.50 max6.00 – 10.00

Inconel 600 Equivalent Grades

UNSWerkstoff Nr.ENJISBSAFNOR
N066002.4816NiCr15FeNCF 600NA 14NC15FE11M

These designations cover the same alloy family; check that the specification on your order allows the designation offered.

Inconel 600 Sheet & Plate Sizes, Cut-to-Size and Finishes

Specification

ASTM B168 / ASME SB168 (UNS N06600)

Thickness

Commonly 0.25 – 100 mm (0.010" – 4")

Common Sheet Sizes

914 × 3048 mm (36" × 120"), 1219 × 3658 mm (48" × 144")

Cut to Size

Pieces, strips, circles and blanks cut to your dimensions on request

Forms

Plate, sheet (including thin shim sheet), strip and coil

Finish

Hot-rolled annealed and pickled (plate); cold-rolled annealed (sheet, strip); other finishes on request
Inconel 600 sheet and plate specification

Certification and Inspection

  •   Mill test certificate: EN 10204 3.1 as standard, with heat number, chemistry and mechanical test results; 3.2 or third-party inspection on request.
  •   Traceability: heat number marked on each plate or sheet, and transferred to cut pieces.
  •   Extra checks on request: positive material identification (PMI), ultrasonic testing of plate, dimensional and flatness checks.

How to Order Inconel 600 Plate: RFQ Example

A complete enquiry lets us quote in one round. Replace the values with your own.

ItemExample
SpecificationASTM B168 / ASME SB168, UNS N06600
Form & conditionHot-rolled plate, annealed
Size & quantity12 mm × 1219 × 2438 mm, 4 plates; or 2 circles 650 mm dia × 25 mm for tubesheets
FinishHot-rolled annealed and pickled
Tests & documentsEN 10204 3.1; PMI; ultrasonic test of plate if required; third-party inspection if required
DeliveryDestination and required date; packing in wooden cases

Send your Inconel 600 sheet or plate RFQ to kamlesh@dineshtube-india.com, call or WhatsApp +91 83559 10913, or send an enquiry.

Where Is Inconel 600 Sheet and Plate Used?

  •   Furnace components: muffles, retorts, baskets and fixtures
  •   Heat-treating and nitriding equipment
  •   Chemical processing, including chlorination and titanium dioxide plants
  •   Nuclear and power plant components
  •   Heat exchanger tubesheets and baffles
  •   Petrochemical equipment

Inconel 600 Sheets & Plates: FAQs

What is the difference between Inconel 600 sheet, plate and strip?

ASTM B168 defines plate as material 5.00 mm (3/16 in.) and thicker and over 250 mm wide, sheet as material under 5.00 mm thick and 600 mm and wider, and strip as cold-rolled material under 5.00 mm thick and under 600 mm wide. Tell us the thickness and width you need and we quote the right product form.

Which standard covers Inconel 600 sheet and plate?

ASTM B168 / ASME SB168 covers UNS N06600 plate, sheet and strip, with general requirements in ASTM B906. Other specifications that may be named on orders include SAE AMS 5540 and DIN 17750 / EN 10095 (W.Nr. 2.4816, NiCr15Fe).

What are the minimum mechanical properties of Inconel 600 plate?

Under ASTM B168, hot-rolled annealed plate has a minimum tensile strength of 550 MPa (80 ksi), minimum yield strength of 240 MPa (35 ksi) and 30% minimum elongation; hot-rolled as-rolled plate has a 586 MPa (85 ksi) minimum tensile strength with the same yield and elongation. The minimums depend on the product condition, so state annealed or as-rolled in your order.

Can you supply Inconel 600 plate for tube sheets?

Yes. We supply Inconel 600 plate cut to circles or blanks to the tubesheet diameter and thickness you give us. Drilling, machining and cladding of the tubesheet are carried out by the exchanger fabricator.

Is Inconel 600 the same as Inconel 601 or 625?

No. Alloy 601 adds aluminium for better oxidation resistance, and alloy 625 adds molybdenum and niobium for higher strength and corrosion resistance. They have different specifications and properties, so order the grade your drawing or data sheet names.

What should an Inconel 600 plate enquiry include?

Give the specification (ASTM B168 / ASME SB168, UNS N06600), product form and condition (for example hot-rolled annealed plate), thickness, width and length or cut size and quantity, finish, tests, documents (EN 10204 3.1, plus 3.2 or third-party inspection if required) and the delivery date.

Export Destinations for Inconel 600 Sheets & Plates

We supply Inconel 600 sheets and plates within India and export to customers in the Middle East, Africa, Asia (including Japan), Europe and the Americas. Tell us your destination port when you send your RFQ.

Inconel® is a registered trademark of Special Metals Corporation. Dinesh Tube India is an independent supplier and is not affiliated with the trademark owner.
