Ta-2.5W Tantalum-Tungsten Sheet, Plate, Strip and Foil to ASTM B708
Dinesh Tube India supplies tantalum R05252 sheets, plates, strip and foil from Mumbai to chemical-equipment fabricators, heat-exchanger and tube makers, and high-temperature and research buyers. UNS R05252 is Ta-2.5W, tantalum alloyed with about 2.5% tungsten, supplied to ASTM B708 / ASME SB708 with EN 10204 3.1 mill test certificates.
The tungsten makes R05252 about a third stronger than unalloyed tantalum, while it keeps almost the same corrosion resistance and still forms and welds well. That makes it a good choice where pure tantalum is too soft but Ta-10W would be too hard to form. For other grades and the full corrosion guide, see our tantalum sheets and plates page.
Tantalum R05252 vs R05200 vs Ta-10W Sheet
| Point | R05200 (unalloyed) | R05252 (Ta-2.5W) | R05255 (Ta-10W) |
|---|---|---|---|
| Tungsten | 0.05% max | 2.0–3.5% | 9.0–11.0% |
| Min. tensile strength (annealed) | 172–207 MPa (25–30 ksi) | 276 MPa (40 ksi) | 482 MPa (70 ksi) |
| Forming and welding | Excellent | Very good | Good, but harder to form |
| Corrosion resistance | Reference | Close to unalloyed tantalum | Slightly lower in some media |
| Choose it for | Linings, glass-lined vessel patches | Thinner linings, strip for welded tube, stiffer formed parts | High-strength and high-temperature parts |
Tantalum R05252 Chemical Composition (ASTM B708, %)
Typical B708 limits. Check the current ASTM B708 edition (B708-25) and the mill certificate for governing values.
Tantalum R05252 Mechanical Properties (Annealed, Minimum)
Physical Properties (approx.)
Why Choose Ta-2.5W Sheet?
Corrosion Resistance of R05252
Ta-2.5W behaves almost the same as unalloyed tantalum. It resists hot hydrochloric, sulphuric (below about 175 °C) and nitric acids, wet chlorine, bromine and chloride salts. Like all tantalum, it is not suitable for hydrofluoric acid and fluorides, fuming sulphuric acid (free SO3) or hot strong alkalis, and it can absorb hydrogen and become brittle if coupled to more active metals. See the full guide on our tantalum sheets and plates page.
Ta-2.5W Sheet Weight Calculation
Weight (kg) = Length (m) × Width (m) × Thickness (mm) × 16.7
For example, a 1000 mm × 500 mm × 1 mm R05252 sheet weighs about 1 × 0.5 × 1 × 16.7 = 8.4 kg, roughly twice the weight of the same sheet in steel.
Need tantalum R05252 sheet, plate or strip? Send the thickness, sizes or drawing, quantity and process media to kamlesh@dineshtube-india.com or call +91 83559 10913. You can also send an enquiry.
Tantalum R05252 Sheet & Plate Applications
Tantalum R05252 Sheets & Plates: FAQs
What is tantalum UNS R05252 sheet?
UNS R05252 is Ta-2.5W, a tantalum alloy with about 2.0–3.5% tungsten. It is supplied as sheet, plate, strip and foil to ASTM B708 / ASME SB708, and as tube to ASTM B521.
What is the difference between R05252 and R05200 sheet?
R05200 is unalloyed tantalum. R05252 adds about 2.5% tungsten, which raises the minimum tensile strength to about 276 MPa while keeping almost the same corrosion resistance and good formability.
When should I choose Ta-2.5W instead of Ta-10W?
Choose Ta-2.5W when pure tantalum is too soft but you still need easy forming and welding, for example in linings, formed parts and strip for welded tube. Ta-10W (R05255) is much stronger but harder to form, and suits high-strength or high-temperature parts.
Can R05252 be used for tantalum-lined tubesheets?
Yes. Ta-2.5W sheet can be used for tantalum linings and cladding on tubesheets, vessels and columns, where its extra strength allows thinner tantalum than unalloyed R05200. Send the tubesheet drawing and thickness for a quote.
What thicknesses of R05252 sheet are available?
Typically foil and strip from about 0.05 mm to 0.5 mm, and sheet and plate from 0.5 mm to about 6 mm, with 1 mm and 2 mm the most common. Other sizes and cut blanks can be quoted on request.
What is the price of tantalum R05252 sheet?
The price depends on thickness, size, quantity and current metal prices. Send your requirement to kamlesh@dineshtube-india.com or call +91 83559 10913 for a current quote.
Which certificates come with R05252 sheets and plates?
Every supply comes with an EN 10204 3.1 mill test certificate showing lot number, chemical analysis and mechanical properties to ASTM B708. EN 10204 3.2 certificates and third-party inspection can be arranged on request.
